FG Wilson P330-5 Diesel Generator LSA DSE Connect
3 Images
- Price From: £33,425.00 Excl. VAT
- Condition: New
- Stock: Contact us for Availability.
- Incoming Stock: 3 Unit/s Due In Jun 2026
- Stock Number: P330-5-Level 2 LSA DSE Connect
FG Wilson P330-5 Diesel Generator LSA DSE Connect
The FG Wilson P330-5 generator is 330 kVA, 264 kW powered by the ultra-reliable Perkins 1506A-E88TAG5 engine and is coupled to a Leroy Somer LL5114J 400/230 volts, 50 Hz alternator to provide prime or standby power. The generator is controlled by a Deep Sea 7410 control panel with a level 2 enclosure for reduced sound levels with a bunded fuel tank. Complete with the FG Wilson Connect which enables remote monitoring and control of the generator set. Suitable for outdoor events, agricultural companies and remote industrial facilities.
The FG Wilson P330-5 diesel generator is complete with manufacturers 1 year warranty on prime units and 2 year warranty on standby.
SPARE PARTS | ACCESSORIES | SERVICING | 01953 458976
- Technical Data
Manufacturer FG Wilson - P330-5 Standby 330.0 kVA / 264.0 kW Prime 300.0 kVA / 240.0 kW Phase Three-Phase Engine Perkins - 1506A-E88TAG5 Alternator Leroy Somer - LL5114J Voltage 400/230 V Frequency 50 Hz Enclosure Level 2 Control Panel Deep Sea - 7410 Emissions Fuel Optimised - Dimensions
Length 3,975 mm Width 1,400 mm Height 1,950 mm Weight 2854.00 kg Please Note: The dimensions and weight are approximate and may be estimated.
- Downloadable Documents
Datasheet: Open Set P330-5 Datasheet: Level 2 Enclosure Datasheet: Deep Sea 7410 Control Panel Manual: Perkins 1506A-E88TAG5 Engine Datasheet: Leroy Somer LL5114J Alternator Datasheet: Perkins 1506A-E88TAG5 Engine Manual: FG Wilson P330-5 Operators Manual: FG Wilson P330-5 Technical Stuart Group Brochure
