FG Wilson P22-6 Diesel Generator
3 Images
- Price From: £7,256.00 Excl. VAT
- Condition: New
- Stock: Contact us for Availability.
- Incoming Stock: 1 Unit/s Due In Apr 2026
- Stock Number: P22-6-CALGL2H
FG Wilson P22-6 Diesel Generator
The FG Wilson P22-6 generator 22 kVA, 17.6 kW is suitable for construction site cabins, residential properties, small retail shops and telecommunications. The generator is powered by the ultra-reliable Perkins 404D-22G engine and is controlled by a Deep Sea 4520 control panel. The generator is coupled to a Leroy Somer LL1114M 400/230 volts, 50 Hz alternator to provide prime or standby power and has a CALGL2H enclosure for reduced sound levels with a standard non-bunded fuel tank.
The FG Wilson P22-6 diesel generator is complete with manufacturers 1 year warranty on prime units and 2 year warranty on standby.
SPARE PARTS | ACCESSORIES | SERVICING | 01953 458976
- Technical Data
Manufacturer FG Wilson - P22-6 Standby 22.0 kVA / 17.6 kW Prime 20.0 kVA / 16.0 kW Phase Three-Phase Engine Perkins - 404D-22G Alternator Leroy Somer - LL1114M Voltage 400/230 V Frequency 50 Hz Enclosure CALGL2H Control Panel Deep Sea - DSE 4520 Emissions EUIIIA Compliant - Dimensions
Length 1,755 mm Width 935 mm Height 1,050 mm Weight 545.00 kg Please Note: The dimensions and weight are approximate and may be estimated.
- Downloadable Documents
Datasheet: Open Set P22-6 Datasheet: CALGL2H Enclosure Datasheet: Leroy Somer LL1114M Alternator Datasheet: Perkins 404D-22G Engine Datasheet: Deep Sea 4520 Control Panel Manual: Perkins 404D-22G Engine Manual: FG Wilson P22-6 Technical Manual: FG Wilson P22-6 Operators Stuart Group Brochure
