- Price From: £7,181.00 Excl. VAT
- Condition: New
- Stock: Contact us for Availability.
- Incoming Stock: 1 Unit/s Due In Jul 2026
- Stock Number: P22-6-CALGL2H CON
FG Wilson P22-6 Diesel Generator Connect
The FG Wilson P22-6 generator 22 kVA, 17.6 kW is powered by the ultra-reliable Perkins 404D-22G engine and is coupled to a FG Wilson FGL10060 400/230 volts, 50 Hz alternator to provide prime or standby power. The generator is controlled by a Deep Sea 4520 control panel and has a CALGL2H enclosure for reduced sound levels with a standard non-bunded fuel tank. Complete with the FG Wilson Connect which enables remote monitoring and control of the generator set. Suitable for construction site cabins, residential properties, small retail shops and telecommunications.
The FG Wilson P22-6 diesel generator is complete with manufacturers 1 year warranty on prime units and 2 year warranty on standby.
- Technical Data
Manufacturer FG Wilson - P22-6 Standby 22.0 kVA / 17.6 kW Prime 20.0 kVA / 16.0 kW Phase Three-Phase Engine Perkins - 404D-22G Alternator FG Wilson - FGL10060 Voltage 400/230 V Frequency 50 Hz Enclosure CALGL2H Control Panel Deep Sea - DSE 4520 Emissions EUIIIA Compliant - Dimensions
Length 1,755 mm Width 935 mm Height 1,050 mm Weight 545.00 kg Please Note: The dimensions and weight are approximate and may be estimated.
- Downloadable Documents
Datasheet: Open Set P22-6 Datasheet: CALGL2H Enclosure Datasheet: FG Wilson FGL10060 Alternator Datasheet: Perkins 404D-22G Engine Datasheet: Deep Sea 4520 Control Panel Manual: Perkins 404D-22G Engine Manual: FG Wilson P22-6 Operators Manual: FG Wilson P22-6 Technical Stuart Group Brochure
