FG Wilson P22-1 Diesel Generator LSA
3 Images
- Price From: £7,079.00 Excl. VAT
- Condition: New
- Stock: 1 Unit/s in Stock
- Incoming Stock: 2 Unit/s Due In Jul 2026
- Stock Number: P22-1-CALGL2H
FG Wilson P22-1 Diesel Generator LSA
The FG Wilson P22-1 generator 22 kVA, 17.6 kW is coupled to a Leroy Somer LL1114M 400/230 volts, 50 Hz alternator and is powered by the ultra-reliable Perkins 404A-22G1 engine to provide prime or standby power. The generator is controlled by a Deep Sea 4520 control panel and has a CALGL2H enclosure for reduced sound levels with a standard non-bunded fuel tank. The P22-1 generator is suitable for construction site cabins, residential properties, small retail shops and telecommunications.
The FG Wilson P22-1 diesel generator is complete with manufacturers 1 year warranty on prime units and 2 year warranty on standby.
SPARE PARTS | ACCESSORIES | SERVICING | 01953 458976
- Technical Data
Manufacturer FG Wilson - P22-1 Standby 22.0 kVA / 17.6 kW Prime 20.0 kVA / 16.0 kW Engine Perkins - 404A-22G1 Alternator Leroy Somer - LL1114M Voltage 400/230 V Frequency 50 Hz Enclosure CALGL2H Control Panel Deep Sea - DSE 4520 Emissions Fuel Optimised - Dimensions
Length 1,755 mm Width 935 mm Height 1,055 mm Weight 545.00 kg Please Note: The dimensions and weight are approximate and may be estimated.
- Downloadable Documents
Datasheet: Open Set P22-1 Datasheet: CALGL2H Enclosure Datasheet: Leroy Somer LL1114M Alternator Datasheet: Perkins 404A-22G1 Engine Datasheet: Deep Sea 4520 Control Panel Manual: Perkins 404A-22G1 Engine Manual: FG Wilson P22-1 Operators Manual: FG Wilson P22-1 Technical Stuart Group Brochure
