Tsurumi KTVE Automatic Drainage Pumps
The KTVE pumps offer an automatic option to the KTV series, without the need for external control panels and cumbersome float switches. A sensor probe is mounted in a durable, moulded rubber bracket and, for added protection, it is positioned within the footprint of the pump base. Once the water level reaches the probe, the pump will start and continue to operate for one minute after the water falls below it. However, if the water level touches the probe within this time, the “stop” signal is cancelled and the pump continues to run until the water is cleared. To enable a lower “on level” (by a further 90mm), the sensor probe can be lengthened by fitting the electrode extender, which is an optional extra.
Special use option: IDS (individually screened cable) on 3.7kW and 5.5kW models. (Please request a quotation)
- Technical Data
Condition New Manufacturer Tsurumi Model / Part KTVE Automatic Outlet (BSPM/mm) 2"/50mm - 3"/75mm Motor output (kW) 0.75 - 5.5 Phases 3 Max head (m) 15 - 35 Max flow (I/min) 320 - 980 Free passage (mm) 6 - 8.5 - Model Variants
Model Manual/Auto Outlet Volt kW Flow Head Weight Model: KTVE2.75 Manual/Auto: Automatic Outlet: 2 inch Volt: 400 V kW: 0.75 kW Flow: 320.00 l/min Head: 15.00 m Weight: 12.70 kg Model: KTVE21.5 Manual/Auto: Automatic Outlet: 2 inch Volt: 400 V kW: 1.50 kW Flow: 425.00 l/min Head: 20.00 m Weight: 22.00 kg Model: KTVE22.2 Manual/Auto: Automatic Outlet: 2 inch Volt: 400 V kW: 2.20 kW Flow: 525.00 l/min Head: 24.00 m Weight: 25.00 kg Model: KTVE33.7 Manual/Auto: Automatic Outlet: 3 inch Volt: 400 V kW: 3.70 kW Flow: 830.00 l/min Head: 26.00 m Weight: 40.00 kg Model: KTVE35.5 Manual/Auto: Automatic Outlet: 3 inch Volt: 400 V kW: 5.50 kW Flow: 980.00 l/min Head: 35.00 m Weight: 52.00 kg - Downloadable Documents
