Tsurumi HS Automatic Single Phase Industrial Pumps
For the automatic control of water levels, the HS series is available with sensor and float switches: The Sensor switch has two 304 stainless steel probes that are encapsulated in moulded rubber and it is designed for portable applications. The compact design and precise water level control also makes it suitable for fixed installations and narrow or shallow sumps. During use, when both probes touch water, the pump will start and continue to operate for one minute after the water level drops. However, if the water touches both probes again within this time, the pump continues pumping for another minute and will continue like this on demand, so keeping the water level constantly below the level of the probes at all times. The off level can be as low as the level of the water entry of the volute at 50mm, depending on the sump size or area being drained. Probes can be lengthened by 70mm or 170mm, with optional extensions, to enable a lower “on” and “off” level.
The Pendant float-switch has a power cable connected to a waterproof case that contains a ball bearing actuated switch and is designed for portable and fixed installations. The cable is clamped to the pump, with a small amount of adjustment to alter the “on” and “off” level.
The AGMA float-switch has a switch actuated by a floating cylinder, housed within a tube. Compact, with fixed “on” and “off” levels for precise level control, it is intended for narrow sumps and fixed installations.
- Technical Data
Condition New Manufacturer Tsurumi Model / Part HS Automatic Outlet (mm) 50 - 75 Motor output (kW) 0.4 - 0.75 Phases 1 Max head (m) 10.8 - 18 Max flow (I/min) 205 - 580 Free passage (mm) 7 - Model Variants
Model Manual/Auto Outlet Volt kW Flow Head Model: HS2.4S Manual/Auto: Pendant Outlet: 2 inch Volt: 110 V kW: 0.40 kW Flow: 205.00 l/min Head: 12.00 m Model: HS2.4S Manual/Auto: Pendant Outlet: 2 inch Volt: 230 V kW: 0.40 kW Flow: 205.00 l/min Head: 12.00 m Model: HS2.4S Manual/Auto: AGMA Outlet: 2 inch Volt: 230 V kW: 0.40 kW Flow: 205.00 l/min Head: 12.00 m Model: HS2.4S Manual/Auto: Sensor Outlet: 2 inch Volt: 110 V kW: 0.40 kW Flow: 205.00 l/min Head: 12.00 m Model: HS2.4S Manual/Auto: Sensor Outlet: 2 inch Volt: 230 V kW: 0.40 kW Flow: 205.00 l/min Head: 12.00 m Model: HS2.75S Manual/Auto: Pendant Outlet: 2 inch Volt: 110 V kW: 0.75 kW Flow: 230.00 l/min Head: 18.00 m Model: HS2.75S Manual/Auto: Sensor Outlet: 2 inch Volt: 110 V kW: 0.75 kW Flow: 230.00 l/min Head: 18.00 m Model: HS2.75S Manual/Auto: Pendant Outlet: 2 inch Volt: 230 V kW: 0.75 kW Flow: 230.00 l/min Head: 18.00 m Model: HS2.75S Manual/Auto: AGMA Outlet: 2 inch Volt: 230 V kW: 0.75 kW Flow: 230.00 l/min Head: 18.00 m Model: HS2.75S Manual/Auto: Sensor Outlet: 2 inch Volt: 230 V kW: 0.75 kW Flow: 230.00 l/min Head: 18.00 m Model: HS3.75S Manual/Auto: Pendant Outlet: 75 mm Volt: 110 V kW: 0.75 kW Flow: 310.00 l/min Head: 18.00 m Model: HS3.75S Manual/Auto: Sensor Outlet: 75 mm Volt: 110 V kW: 0.75 kW Flow: 230.00 l/min Head: 18.00 m Model: HS3.75S Manual/Auto: Pendant Outlet: 75 mm Volt: 230 V kW: 0.75 kW Flow: 310.00 l/min Head: 18.00 m Model: HS3.75S Manual/Auto: AGMA Outlet: 75 mm Volt: 230 V kW: 0.75 kW Flow: 310.00 l/min Head: 18.00 m Model: HS3.75S Manual/Auto: Sensor Outlet: 75 mm Volt: 230 V kW: 0.75 kW Flow: 310.00 l/min Head: 18.00 m Model: HS3.75SL Manual/Auto: Pendant Outlet: 75 mm Volt: 110 V kW: 0.75 kW Flow: 580.00 l/min Head: 10.80 m Model: HS3.75SL Manual/Auto: Sensor Outlet: 75 mm Volt: 110 V kW: 0.75 kW Flow: 580.00 l/min Head: 10.80 m Model: HS3.75SL Manual/Auto: Pendant Outlet: 75 mm Volt: 230 V kW: 0.75 kW Flow: 580.00 l/min Head: 10.80 m Model: HS3.75SL Manual/Auto: AGMA Outlet: 75 mm Volt: 230 V kW: 0.75 kW Flow: 580.00 l/min Head: 10.80 m Model: HS3.75SL Manual/Auto: Sensor Outlet: 75 mm Volt: 230 V kW: 0.75 kW Flow: 580.00 l/min Head: 10.80 m - Downloadable Documents
