Pramac OFF GRID LX 45/90 Battery Storage Unit


  • Price: Ā£49,919.00 Excl. VAT
  • Stock: Contact us for Availability.
  • Stock Number: LX 45/90

  • Product Description

    Off Grid LX is a universal Battery Energy Storage system (BESS) ideally suited to a range of applications, delivering reliable power in the most cost effective and environmentally sensitive way. Energy stored within the unit is converted electronically into AC power. Power can be derived from connection to an external grid supply, from a diesel generator or solar PV or wind turbine. Energy is automatically managed from any or all of these energy sources to ensure the most efficient, lowest maintenance and best environmental impact is achieved. Remote communication ensures real time monitoring and maintenance can be effected fromany location in the world.

    • Deep cycle maintenance free OPzV-S battery
    • Advanced EMS with touch screen control
    • GSM Remote monitoring
    • Full system DC isolator with pre-charge
    • Auto Full system bypass
    • Single to three phase conversion
  • Product Specifications
    Manufacturer Pramac
    Model OFF GRID LX 45/90
    Prime 45.0 kVA / 90.0 kW
    Phase Three-Phase
    Frequency 50 Hz
    Voltage 400/230 Volts
    Battery (Type) Gel lead acid OPzV-S
    Battery rated Voltage 50 V
    Battery design life (to 80% DoD) 2000 cycles
    Battery Nominal capacity (sizes) 90 kWh
    Usable energy AC side (@80% DoD) 72 kWh
